Hospital Beds

Features

• - Continuous Lateral Rotation Therapy
• - Percussion and Vibration Therapy, including postural option
• - Weight based pressure redistribution in any bed position
• - Advanced Microclimate Management technology
• - Point-Of-Care® siderail controls with Graphical Caregiver Interface feature (GCI®)
• - Digital Head of bed angle indicator and alarm
• - 3 mode bed exit sensor with alarm silence and alarm suspend modes
• - FullChair® and chair egress with stand assist
• - One-button Boost® patient repositioning support
• - Turn assist
• - Optional IntelliDrive® powered transport
• - History data on patient weight, head of bed elevation, chair position, and pulmonary therapies

Specifications

• - Overall Length: FlexAfoot Extended 93", FlexAfoot Retracted 81.5"
• - Overall Width: Siderails Stowed 38", Rails Up 40"
• - Max Head Elevation: 75°
• - Maximum Weight Capacity: 500lbs

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - Auto Contour Complete Therapeutic Positioning
• - Chair Position
• - Central Brake and Steering Dynamic Air Sleep Surface
• - Patient and Staff Controls on Head Rails
• - Automatic Night Light

Specifications

• - Caster: 5"
• - Overall Dimensions: 41.50"W 93.50"L
• - Sleep Dimensions: 36" x 84"
• - Maximum Weight Capacity: 500lbs.
• - Height Range: 17" to 30"
• - Hi-Low Travel Time: 21sec.

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - Boost one-button feature helps patients move toward the head of the bed
• - IntelliDrive powered transport lets staff handle the bed effortlessly
• - Point of Care control panel uses easy to read digital display and simple icons
• - Fully featured low bed can be adjusted to the optimal height for patient care with full functionality in the lowest position
• - Hands free foot pedal system allows caregivers to raise or lower the head of the bed and height of the bed without using their hands
• - Low chair position allows patients to be placed in an upright position while keeping the bed low
• -

Specifications

• - Bed Height: High Position 34", Low Position 17"
• - Overall Width: 40" (Siderails Down: 37")
• - Overall Length: Fully Extended 94.50", Fully Retracted 82.50"
• - Max Head Elevation: 0° to 65°
• - Max Foot Section: 0° to 27°
• - Max Patient Weight Limit: 500lbs

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - Fully Function Test
• - Basic Bed Function: Head, Knee, Hi-Low
• - Spring sleep surface (Standard) or Orthopedic/Hard pan surface (Upgrade)
• - New PC Boards (5 Year Warranty)
• - New motor couplings and capacitors
• - Rebuilt caster with new components and wheels
• - Delivery/Installation available upon request (Domestic Only)

Specifications

• - Total Length: 92.50"
• - 5" Caster
• - Bed Lift Capacity: 500lbs
• - Trendelenburg/Reverse Trend
• - Central Brake and Steer
• - Sleep Surface: 35" x 83"
• - Height Range: 14.50" to 33.50"
• - Full Chair Position

Optional

• - Side Guard Communications
• - Percussion and Vibration Module
• - Rotation Module
• - Two-Layer Therapeutic Surface

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - Open architecture allows the flexibility to choose any sleep surface
• - Retractable bed frame helps keep patients close to their belongings regardless of bed articulation
• - 6" (15 cm) casters
• - Dual pedestal design
• - CPR release
• - In-rail fowler/kneed gatch control
• - Electronic function lock-out control
• - Four-wheel, steel-ring brake system with centrally-located activation pedals
• - Backrest angle indicator
• - Locking-caster steering
• - Four traction sockets
• - Removable headboard with CPR capability
• - Retractable litter top
• - Four foley bag hooks
• - Four IV receptacles
• - Patient restraint locations
• - Trend reverse and Trend controls

Specifications

• - Overall Length: 93" (236 cm)
• - Overall Width: Siderails Up: 42.5" (108 cm), Siderails Down: 40" (102 cm)
• - Weight Capacity: 500 lbs
• - Backrest: 0° to 60°
• - Knee Gatch: 0° to 40°
• - Trend. / Reverse Trend. +/- 12 degrees (+/-10 degrees with ZX option)
• - Retraction: 14"
• - Patient Surface: 35" x 84"
• - 6" Caster

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - BackSmart Design
• - Chaperone Bed Exit System
• - Integrated Scale
• - Open Architecture
• - Exceptional Low Height
• - Complete Siderail Controls
• - Retractable Fifth Wheel
• - Intuitive Siderail Control
• - Integrated Pump Holder
• - Cardiac Chair Positioning
• - Manual Back-up

Specifications

• - Overall Length: 94.25"
• - Overall Width: 40", with Siderails Down 39"
• - Weight Capacity: 500lbs.
• - Height: High 29", Low 14.50"
• - Backrest Positioning: 0° to 60°
• - Knee Gatch: 0° to 28°
• - Patient Surface: 36" x 84"
• - 6" Caster

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - Siderail and footboard positioning controls
• - Cardiac chair/ Emergency drop
• - Backrest Trend/ angle display
• - Radiolucent from neck through pelvic region
• - Scale-isolated drainage bag hooks/head end IV poles
• - Integrated 8" bed extender
• - Four-wheel, steel ring brake system with centrally located activation pedals
• - 90 degree backrest for upright chest imaging
• - Dual pedestal design
• - CPR release for backrest and knee
• - Locking caster steering
• - Four traction sockets
• - Four IV receptacles (scale isolated at head end)
• - Electric function lock-out controls
• - In-rail backrest/knee catch controls
• - Removable CPR board

Specifications

• - Overall length- 91"
• - Overall width- side rails up: 42.5"
• - Overall width- side rails down: 40"
• - Height-low (to litter top) 18"
• - Height-high (to litter top) 32.5"
• - Knee/Gatch angle: 0 degree to 30 degree
• - Back/Fowler angle: 0 degree to 90 degree
• - Trend- 12 degree
• - Reverse Trend- +12 degree
• - Patient surface: 35" x 84"
• - Patient weight: 500 lbs

Refurbishment Process

• - Completely disassemble bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - New pad
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - 1 year warranty

Features

• - Zoom drive
• - Scale
• - Bed exit
• - IBED
• - Bed controls
• - options screen
• - CPR foot peddle
• - Battery back-up
• - Touch screen controls

Specifications

• - 550 lb weight capacity

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty

Features

• - The BariMaxx™ Active Therapy System includes the AtmosAir™ 9000E mattress with Self-Adjusting Technology™ (SAT™).
• - The AtmosAir™ 9000E with SAT™ supports and distributes patient weight automatically to relieve pressure and enhance comfort.

Specifications

• - Length: 203 cm (224 cm with optional foot extension)
• - Width: 90 cm (123 cm with optional side extensions)
• - Height: 19 cm
• - Weight: 20 kg
• - Maximum patient weight: 455 kg
• - Cover: Dartex two-way stretch, breathable medical fabric to reduce shear and friction
• - Bed Frame -> Weight: 425 kg
• - Bed Frame -> Height to mattress support surface (Min/Max): 44/66 cm
• - Bed Frame -> Overall Length (retracted): 240 cm
• - Bed Frame -> Overall Length (expanded): 255 cm
• - Bed Frame -> Overall Width (side rails retracted): 109 cm
• - Bed Frame -> Overall Width (side rails expanded): 142 cm
• - Bed Frame -> Safe working load: 455 kg
• - Foot of bed and hand pendant controls
• - NElectrical
• - Voltage: 230 V
• - Frequency: 50/60 Hz
• - Amps: 10 A

Refurbishment Process

• - Disassemble Bed
• - Steam clean frame and components
• - Paint frame
• - Install new brake mechanisms on both sides
• - Sand and repaint shrouds with our special 2 part polyurethane coating
• - Rebuild pumps with new seals and adjust pumps speed and travel
• - New stickers per customers choice of color
• - Clean,adjust and lube brake/steer components
• - New bumpers and plastic
• - 1 year warranty
