Surgical Lights

Features

• - Excellent depth of illumination and low shadow levels, using polygon reflector elements.
• - Cool light in the surgical area achieved by filtering out the infrared proportion by means of the proven ThermoSorb® double filter system.
• - Impact-absorbent light hood prevents deformations and paint defects.
• - Suspension system and the hand grip with protective collar and an integrated release mechanism, ensure a high degree of hygiene.
• - Instant-on back-up bulb: In the event of failure of the main lamp, the reserve lamp swivels automatically into position to maintain constant lighting.

Specifications

• - Reflector System: Polygonreflector
• - Color Temperature: 4300K
• - Intensity Ec at 1m: 160 klx
• - Intensity Control: 80 - 160 klx
• - Light Field Diameter: 17 - 30 cm
• - BRITe-bulb: 22.8V/ 150W
• - Lifetime of BRITe-bulb: 1000hrs
• - CRI: 93
• - Power Consumption: 240 VA
• - Rotation: 360°
• - Weight with transformer/ switching power supply: 110lbs

Refurbishment Process

• -

Features

• - Shadow control provides the most accurate color rendition for improved diagnosis.
• - Available with a five-caster base or single and dal ceiling mounts
• - Requires less than 2.5lbs of force to move light
• - Fully autoclavable handle
• - Truer color temperature with less heat

Specifications

• - Pattern Diameter: 8"
• - Depth Of Field: 35"
• - Color Temperature: 4,200 K
• - Diameter Of Lighthead: 17"
• - Bulb: 100-watt Halogen Lamp

Refurbishment Process

• -

Features

• - Deep cavity illumination and minimal shadow interface
• - Less heat-causing light protects delicate tissue
• - Center Mounted Suspension System
• - Variable Intensity Controller

Specifications

• - Depth of Illumination: 43"
• - Color Temperature: 4,400K
• - Intensity: 160,000 Lux
• - Pattern Size: 6" - 11"
• - Color Rendering Index: 94
• - Light Head Diameter: 20"

Refurbishment Process

• -
